8 PRODUCT OVERVIEW
• The silverware basket ships installed at the back
of the bottom rack. For best performance, install
it along the right side.
• Remove all packing materials from the exterior
and interior of the dishwasher before installing
the appliance.
• Press the tab to remove the cable tie by hand.
Cutting the tie with a knife or scissors may
damage the rack or the silverware basket.
Accessories
a Installation Brackets (2 ea)
b Wood Screws (4 ea)
c Hose Clamp
Product Specifications
The appearance and specifications listed in this
manual may vary due to constant product
improvements.
Model LDFC242**
Electrical
Requirements
120 V, 60 Hz AC only,
15 A circuit breaker
Water Pressure 20 psi - 80 psi
(140 kPa - 550 kPa)
Dimensions
(Width X Depth X
Height)
23 3/4” X 24 5/8” X 33 5/8”
(603 mm X 625 mm X 854
mm)
Inlet Water
Temperature
120 ℉ - 149 ℉
(49 ℃ - 65 ℃)
Net Weight 66 lbs. - 75 lbs.
(30 kg - 34 kg)
