8 PRODUCT OVERVIEW
• Remove all packing materials from the exterior
and interior of the dishwasher before installing
the appliance.
• Press the tab to remove the cable tie by hand.
Cutting the tie with a knife or scissors may
damage the rack or the silverware basket.
Accessories
a Installation Brackets (2 ea)
b Wood Screws (4 ea)
c Hose Clamp
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product improvements.
Model LDFN343**
Electrical Requirements 120 V, 60 Hz AC only, minimum 15 A circuit breaker
Min. / Max. Water Pressure 20 psi - 80 psi (140 kPa - 550 kPa)
Dimensions
(Width X Depth X Height)
23 3/4” X 24 5/8” X 33 5/8”
(603 mm X 625 mm X 854 mm)
Inlet Water Temperature 120 °F (49 °C) minimum, 149 °F (65 °C) maximum
Net Weight 70 lbs. (31.8 kg)
