LG LGSBWAC03

User Manual
PAGE :
DOCUMENT No :
REG. DATE : 2020.05.26
MODEL NAME: ETWCFMBC02(LGIT)
LGSBWAC03(LGE)
REV. DATE : 2020.05.26
REV.NO : V1.0
-
Copyrightⓒ. 2020. All Rights Reserved.
2 / 9
2. Picture of Product
1. Features
LGSBWAC03 is the small size and low power module for IEEE 802.11ac wireless LAN
& BT5.0 + HS. ETWCFMBC02 is based on Mediatek MT7663BUN solution.
 IEEE 802.11 a/b/g/n/ac
 Bluetooth 5.0+ HS , BLE
 Size : 68.0mm x 30.0 x 7.35 mm
 Two stream spatial multiplexing up to 300Mbps(802.11n) / 867Mbps(802.11ac)
Use on-chip OTP (One-Time Programmable)
 Host Interface : USB2.0 (WLAN & BT)
- This model is using the common USB2.0 to control WLAN and BT
 Security : WAPI, WEP, WPA, WPA2, WMM, AES, TKIP, CKP
 Application: DTV, DVR, HD DVD Player, Blue-ray Disk Player, STB
