INSTALLATION IN CASEMENT STYLE WINDOWS
INSTALLATION INSTRUCTIONS
21
English
Insert the diffuser into the Vent Panel. And
then slide.
If you want fix the diffuser more firmly, use
the type C screw.
Small gap
First
Insert
Second
Slide
First insert to the vent panel fully and then
slide for locking.
Type C screw
5
