38
Ch5. Removing and replacing a part
■ 1020 Hard Disk Drive
Remove the following parts in order before replacing this part
1. Battery Pack(1010) 2. Battery Pack(1010)
1. Remove a screw as indicated in the picture, then pull the HDD Assy out in the direction shown below.
2M2.5 X L3.51SZZBA4063B1
QtySpecificationFRU No.No.
