LG LS70 - Page 45

44
Ch5. Removing and replacing a part
■ 1060 Keyboard Plate
Remove the following parts in order before replacing this part
1. Battery Pack(1010) 2. Hard Disk Drive(1020) 3. W/L LAN Card(1030) 4. Keyboard(1040)
5. Retainer(1050)
1. Remove 7 screws and remove Keyboard Plate.
7M2.0 X L3.51SZZBA4023A1
QtySpecificationFRU No.No.
