46
Ch5. Removing and replacing a part
■ 1080 Hinge Cover
Remove the following parts in order before replacing this part
1. Battery Pack(1010) 2. Hard Disk Drive(1020) 3. W/L LAN Card(1030) 4. Keyboard(1040)
5. Retainer(1050) 6. Keyboard plate(1060) 7. Keyboard plate(1070)
1. Using a screw driver, remove Hinge Cover. (Left / Right)
To Next Page
