LG LTNS16121V /00 - Condenser Fan Error

- Condenser Fan Error
47
Symptom Check Point
1. Condenser Fan Error
1. Check the air flow
2. Check the fan motor and connector
3. Check the PCB Fan motor voltage
TEST MODE 1 Voltage [V]
CON5
1
st
pin ~ 2
nd
pin
8V~13V
CON5
2
nd
pin ~ 3
th
pin
Not 0V, 5V
Fan Motor
CON5
Image represents error
on display
CON102 CON2
CON CON8
CON201
CON1
CON6
CON5
