LG M1962D Service Manual

- 9 -
Copyright ©2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
6. Chroma & Brightness
6.3 Optical Test Condition
- Surrounding Brightness Level : dark
- Surrounding Temperature : 25±5°C
- warm-up Time :30 Min
- Contrast,Brightness : Outgoing condition
-.*Incase of Vivid Mode, high level saturation may be occurred. Check gray linearity at standard mode.
6.1 M2262D – AUO Module
No. Item
Specification
Remark
Min typ Max
1. Viewing Angle<CR>10>
Horizontal 150 170 -
Vertical 140 160 -
2. Luminance
Luminance (cd/m2) 240 300 -
Variance(%) 75 80 -
3. Contrast Ratio CR 600 1000 - Full White/ Full black
White Wx 0.313
Wy 0.329
RED Rx Typ 0.618 Typ DVI or RGB
4. Color Coordinates Ry -0.03 0.309
+0.03
- Vivid, 6500K
[CIE 1931] Green Gx 0.252 - Full White (100IRE)
Gy 0.573 - Backlight 100
Blue Bx 0.113
By 0.040
Rise Time Tr
R 3.8 5.5 Condition : DVI or RGB
5. Response Time
Decay Time Tr
D 1.2 2.5 Standard, Backlight100
6.2 M2262D – LGD Module
No. Item
Specification
Remark
Min typ Max
1. Viewing Angle<CR>10>
Right/ Left 70/ 70 85/ 85 -
Up/ Down 60/ 70 75/ 85 -
2. Luminance
Luminance (cd/m2) 250 300 -
Variance(%) 75 - -
3. Contrast Ratio CR 700 1000 - Full White/ Full black
White Wx 0.313
Wy 0.329
RED Rx Typ 0.646 Typ DVI or RGB
4. Color Coordinates Ry -0.03 0.334
+0.03
- Vivid, 6500K
[CIE 1931] Green Gx 0.303 - Full White (100IRE)
Gy 0.616 - Backlight 100
Blue Bx 0.147
By 0.067
Rise Time Tr
R 1.3 2.6 Condition : DVI or RGB
5. Response Time
Decay Time Tr
D 3.7 7.4 Standard, Backlight100
