83
APPENDIX
PRODUCT SPECIFICATIONS
<M1994D>
■
The specifications shown above may be changed without prior notice for quality improvement.
Power
AC100-240V~ 50/60 Hz 0.8A
On Mode : 48W (typ.)
Sleep Mode 1W (RGB Only)
Off Mode 1W
LCD Panel
Screen Type
Pixel Pitch
19 inches Wide (48.141 cm) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 48.141 cm
0.243(H) x 0.243(V)
Max. Resolution
Recommended Resolution
Horizontal Frequency
Vertical Frequency
Synchronization Type
Video Signal
1680 X 1050 @60 Hz
1680 X 1050 @60 Hz
30 - 83 kHz
56 - 75 Hz
Separate Sync, Digital
Input Connector
TV, D-Sub Analog, SCART*2, PC Audio In, component, DVI-D, HDMI*2
Rated Voltage
Power Consumption
Tilt
Tilt Range
-5 ~ 15 °
Dimensions (Width x Height x Depth)
Weight
456.2 x 394.7 x 193.2 mm (17.96 x 15.54 x 7.61 inches)
4.3 kg / 9.48 lbs
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
10 ~ 35°C
20 ~ 80%
-10 ~ 60°C
5 ~ 90%
