LG M2762D Service Manual

- 9 -
Copyright ©2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
6. Chroma & Brightness
6.3 Optical Test Condition
- Surrounding Brightness Level : dark
- Surrounding Temperature : 25±5°C
- warm-up Time :30 Min
- Contrast,Brightness : Outgoing condition
-.*Incase of Vivid Mode, high level saturation may be occurred. Check gray linearity at standard mode.
6.1 M2262D – AUO Module
No. Item
Specification
Remark
Min typ Max
1. Viewing Angle<CR>10>
Horizontal 150 170 -
Vertical 140 160 -
2. Luminance
Luminance (cd/m2) 240 300 -
Variance(%) 75 80 -
3. Contrast Ratio CR 600 1000 - Full White/ Full black
White Wx 0.313
Wy 0.329
RED Rx Typ 0.618 Typ DVI or RGB
4. Color Coordinates Ry -0.03 0.309
+0.03
- Vivid, 6500K
[CIE 1931] Green Gx 0.252 - Full White (100IRE)
Gy 0.573 - Backlight 100
Blue Bx 0.113
By 0.040
Rise Time Tr
R 3.8 5.5 Condition : DVI or RGB
5. Response Time
Decay Time Tr
D 1.2 2.5 Standard, Backlight100
6.2 M2262D – LGD Module
No. Item
Specification
Remark
Min typ Max
1. Viewing Angle<CR>10>
Right/ Left 70/ 70 85/ 85 -
Up/ Down 60/ 70 75/ 85 -
2. Luminance
Luminance (cd/m2) 250 300 -
Variance(%) 75 - -
3. Contrast Ratio CR 700 1000 - Full White/ Full black
White Wx 0.313
Wy 0.329
RED Rx Typ 0.646 Typ DVI or RGB
4. Color Coordinates Ry -0.03 0.334
+0.03
- Vivid, 6500K
[CIE 1931] Green Gx 0.303 - Full White (100IRE)
Gy 0.616 - Backlight 100
Blue Bx 0.147
By 0.067
Rise Time Tr
R 1.3 2.6 Condition : DVI or RGB
5. Response Time
Decay Time Tr
D 3.7 7.4 Standard, Backlight100

LG M2762D Specifications

General

Pixel pitch	0.3114 x 0.3114 mm
Aspect ratio	16:9
Display diagonal	27 \
Separate H/V sync	Yes
Vertical scan range	56 - 75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size diagonal	584.2 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	50000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Display brightness (typical)	300 cd/m²
Bandwidth	0.135 GHz
Display viewable area (HxV)	597.7 x 336.2 mm
Display resolution at frequency	1920 x 1080 @ 60 Hz
USB hub version	2.0
RMS rated power	6 W
Certification	TÜV-Typ, CE, UL, CSA, SEMKO, FCC-B
Product color	Black
Market positioning	-
Compliance industry standards	DDC 2B
LED indicators	Stand-by
Tilt angle range	-5 - 15 °
Panel mounting interface	100 x 100 mm
Power consumption (standby)	1 W
Power consumption (typical)	120 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (without stand)	210 mm
Width (without stand)	654.1 mm
Height (without stand)	494.6 mm
Weight (without stand)	8920 g
