Only for training and service purposes

LGE Internal Use Only

- 22 -

7.HDMI Video Trouble Shooting

Check input signal form at

Is it supported?

Check JK801 / JK802 for proper connectio n or

damage

Replace c onn ector

Check HD MI Cable for damage or open

conn ector

Check ED ID NVRAM

(IC801, IC802)

Power & I2C Signal (#5, #6)

Redownloa d EDID data or

Rep lace IC801/IC802

Check HD CP Key NVRAM (IC105)

Power & I2C Signal (#5, #6)

Replace IC105

Check IC803 Out Volta ge Level

3.3V(Pin 6)

Replace IC803

Replace Ms tar(IC101)
