No Item Specification Remarks
1. Receiving System ATSC/NTSC-M
2. Available Channel 1)VHF :02~13
2)UHF :14~69
3)DTV :02~69
4)CATV :01~135
5)CADTV :01~135
3. Input Voltage 1)AC 100 ~ 240V 50/60Hz Mark: 110V, 60Hz
4. Market North America
5. Screen Size 27inch FHD
6. Aspect Ratio 16:9
7. LCD Module LM270WF1-TLB1 LGD
8. Operating Environment 1)Temp : 0 ~40 deg
2)Humidity : ~80 %
9. Storage Environment 1)Temp : -20 ~60 deg
2)Humidity : ~85 %
4.2 TV
No Item Content Unit Remark
1 Product Width(W) Length(L) Height(H)
Dimension Before Packing 654.1 210 494.6 mm
After Packing 725 535 185 mm
2 Product Only SET 8.92 Kg
With BOX 11.1 Kg
3 Cintaniner 20ft 40ft
Loding
Individual or
Indi. Wooden Indi. Wooden
Quantity
Palletizing
420 330 840 726
4 Stand Assy Type Detachable (Base detachable)
Size (W x D x H) 330.0 x 210.0 x 51.8
Tilt Degree -5~10degree
Tilt force 1.0~3.7kgf
Swivel Degree 358 degree
Swivel Force 0.5 ~2.kgf
5 Appearance General Refer to Standard of LG(55)G1-1020
5. Mechanical specification
