Controlling the Multiple Product
RS-232C
10
Transmission / Receiving Protocol
14. Red Gain Adjust (Command: j w)
To adjust Red color level.
Transmission
[j][w][ ][Set ID][ ][Data][Cr]
Data Min : 00H ~ Max : 64H
Acknowledgement
[w][ ][Set ID][ ][OK][Data][x]
* When it is executed with the 6500K or 9300K selected, it is automatically changed to the USER.
▲
15. Green Gain Adjust (Command: j y)
To adjust Green color level.
Transmission
[j][y][ ][Set ID][ ][Data][Cr]
Data Min : 00H ~ Max : 64H
Acknowledgement
[y][ ][Set ID][ ][OK][Data][x]
* When it is executed with the 6500K or 9300K selected, it is automatically changed to the USER.
▲
16. Blue Gain Adjust (Command: j z)
To adjust Blue color level.
Transmission
[j][z][ ][Set ID][ ][Data][Cr]
Data Min : 00H ~ Max : 64H
Acknowledgement
[z][ ][Set ID][ ][OK][Data][x]
* When it is executed with the 6500K or 9300K selected, it is automatically changed to the USER.
▲
