Controlling the Multiple Product
RS-232C
11
Transmission / Receiving Protocol
17. Tiling Mode (Command :d d)
Change a Tiling Mode.
Transmission
[d][d][][Set ID][][Data][x]
* The data can not be set to 0X or X0 except 00.
Acknowledgement
[d][][00][][OK/NG][Data][x]
18. Tile H Position (Command : d e)
To set the horizontal position.
Transmission
[d][e][][Set ID][][Data][x]
Data Min : 00H ~ Max : 64H
(Hexadecimal code)
Acknowledgement
[e][][Set ID][][OK/NG][Data][x]
Data Description
00 Tiling mode is off.
12 1 x 2 mode(column x row)
13 1 x 3 mode
14 1 x 4 mode
... ...
44 4 x 4 mode
▲
▲
