Controlling the Multiple Product
RS-232C
12
Transmission / Receiving Protocol
19. Tile V Position(Command : d f)
To set the Vertical position.
Transmission
[d][f][][Set ID][][Data][x]
* The data range is from 00 to 64(in Hex).
Acknowledgement
[f][][Set ID][][OK/NG][Data][x]
20. Tile H Size(Command : d g)
To set the Horizontal size.
Transmission
[d][g][][Set ID][][Data][x]
* The data range is from 00 to 64(in Hex).
Acknowledgement
[g][][Set ID][][OK/NG][Data][x]
21. Tile V Size(Command : d h)
To set the Vertical size.
Transmission
[d][h][][Set ID][][Data][x]
* The data range is from 00 to 64(in Hex).
Acknowledgement
[h][][Set ID][][OK/NG][Data][x]
▲
▲▲
