Controlling the Multiple Product
RS-232C
A2
Command Reference List
COMMAND1 COMMAND2 DATA1 DATA2 DATA3
01. Power k a 00H - 01H
02. Input Select k b 02H - 09H
03. Aspect Ratio k c 01H - 09H
04. Screen Mute k d 00H - 01H
05. Volume Mute k e 00H - 01H
06. Volume Control k f 00H - 64H
07. Contrast k g 00H - 64H
08. Brightness k h 00H - 64H
09. Color k i 00H - 64H
10. Tint k j 00H - 64H
11. Sharpness k k 00H - 64H
12. OSD Select k l 00H - 01H
13. Remote Lock/ key Lock k m 00H - 01H
14. Balance k t 00H - 64H
15. Color Temperature k u 00H - 03H
16. Abnormal state k z FFH
17. ISM mode j p 00H - 10H
18. Auto configuration j u 01H
19. Key m c Key Code
20. Tile Mode d d 00H - 55H
21. Tile H Position d e 00H - 64H
22. Tile V Position d f 00H - 64H
23. Tile H Size d g 00H - 64H
24. Tile V Size d h 00H - 64H
25. Tile ID Set d i 00H - 19H
26.
Natural Mode (In Tile mode)
d j 00H - 01H
27. Picture mode(PSM) d x 00H - 06H
28. Sound mode d y 00H - 06H
29. Fan Fault check d w FFH
30. Elapsed time return d l FFH
31. Temperature value d n FFH
32. Lamp fault check d p FFH
33. Auto Volume d u 00H - 01H
34. Speaker d v 00H - 01H
35. Time f a 00H - 06H 00H - 17H 00 - 3BH
36.
On Timer (On/Off Timer) On, Off
f b 00H, FFH 00H - FFH
37.
Off Timer (On/Off Timer) On, Off
f c 00H, FFH 00H - FFH
38.
On Timer (On/Off Timer) Time
f d 00H - 07H 00H - 17H 00 - 3BH
39.
Off Timer (On/Off Timer) Time
f e 00H - 07H 00H - 17H 00 - 3BH
40.
Sleep Time
f f 00H - 08H
41. Auto Sleep f g 00H - 01H
42. Power On Delay f h 00H - 64H
43. Language f i 00H - 09H
44. DPM Select f j 00H - 01H
45. Reset f k 00H - 02H
