5-4
D. DOOR GROSS ASSEMBLY REMOVAL
1) Open the door.
2) Remove the choke cover cap very carefully with a flat-
blade screwdriver.
CAUTION : Be careful not to damage door seal plate with
the screwdriver.
3) Lift up and push the door.
NOTE:
1. After replacing the door, be sure to check that the
primary switch, monitor switch, and secondary switch
operate normally.
2. After replacing the door, check for microwave energy
leakage with a survey meter. Microwave energy must be
below the limit of 4 m
W/cm
2
. (with a 275 ml water load)
3. When mounting the door assembly to the oven
assembly, be sure to adjust the door assembly parallel to
the chassis. Also adjust so the door has no play between
the inner door surface and oven frame assembly. If the
door assembly is not mounted properly, microwaves may
leak from the clearance between the door and the oven.
Remove the choke cover cap
To Next Page
