Part 2 Functions & Controls
* Some of functions are slightly different depending upon models, refer individual function table on "PART 2. indoor units".
** For ceiling concealed duct models, auto-run function of dry contact is not applicable.
O : Applied X : Not applied – : No relation
Option : Model name & price are different according to options, and assembled in factory with main unit.
Accessory :
Installed at field, ordered and purchased separately by the corresponding model name, supplied with separate package.
1.2 List of functions
Function
Category
Wall Mounted
(LIBERO)
ART COOL
Mirror
Ceiling Cassette
4-way
Ceiling
Concealed Duct
(Low static)
Air supply outlet 1 1 4 1
Airflow direction control(left & right) Auto Auto X -
Airflow direction control(up & down) Auto Auto Auto -
Auto swing(left & right) O O X -
Auto swing(up & down) O × O -
Airflow steps(fan/cool/heat) 5/6/6 3/4/3 4 / 5 / 4 3 / 3 / 3
Chaos swing X O X -
Chaos wind(auto wind) O X O X
Jet cool/heat(Power wind) O/O O/X O/X O/X
Swirl wind X X O X
Deodorizing filter O O X X
Allergy free filter O X X X
Plasma air purifier O O Option X
Prefilter(washable / anti-fungus) O O O O
Drain pump - - O O
E.S.P. control - - - O
Electric heater(operation) - - X X
High ceiling operation - - O -
Hot start O O O O
Self diagnosis O O O O
Soft dry operation O O O O
Auto changeover X X X X
Auto cleaning O O X X
Auto operation(artificial intelligence) O O O O
Auto restart operation O O O O
Child lock O - O O
Energy-Saving Cooling Mode O X X X
Forced operation O O O X
Group control - - O O
Sleep mode O O O X
Timer(on/off) O O O X
Timer(weekly) O - O X
Two thermistor control O - O O
Wide wired remote controller Accessory Accessory Accessory Accessory
Deluxe wired remote controller X X X X
Simple wired remote controller Accessory Accessory Accessory O
Simple wired remote controller(for hotel use) Accessory Accessory Accessory Accessory
Wireless remote controller(simple) X X X X
Wireless LCD remote control X X X X
Wireless LCD remote control(Ez) O O O Accessory
General central controller (Non LGAP) X X X X
Dry contact Accessory Accessory Accessory Accessory
Dry contact(temperature setting) Accessory Accessory Accessory Accessory
Central control(LGAP) O O O O
PDI(power distribution indicator) Accessory Accessory Accessory Accessory
PI 485 Accessory Accessory Accessory Accessory
CTIE X X - X
Zone control X X - X
Thermistor - - - -
Air flow
Air purifying
Installation
Reliability
Convenience
Individual
control
Special
function kit
Others
CAC network
function
