5. Trouble Shooting
- 56 -
Copyright ©2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
09
Indoor EEPROM Check
Sum Error
• Check sum error
1. Check the poor soldering
2. Check the insertion condition of the EEPROM
3. Check the PCB Connection
Display
code
Title Cause of error Check point & Normal condition
Check Point
1. Check the EEPROM Direction
2. If the EEPROM value & the Program value are not matched, the Code is Displayed
3. After Checking the connection and Insertion, replace the PCB or Option PCB
