33
ENGLISH
CAUTION
• Ask an authorized technician to setting a function.
• If do not use a function, set an off-mode.
• If use a function, capacity may go down.
!
Master unit PCB DIP switch on : No.5
Select the mode using ‘▶’, ‘◀’ Button :
“Func” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Fn21” Push the ‘●’ button
Select the Option using ‘▶’, ‘◀’ Button :
“SPL0”,“SPL1”,”Pd10”,”Pd11”Push the ‘●’
button
Power Consumption Display on wired remote
controller Mode is set
Master unit PCB DIP switch on : No.5
Select the mode using ‘▶’, ‘◀’ Button :
“Func” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Fn21” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Fn22” Push the ‘●’ button
Overall Defrost Operating in Low Mode is set
Setting Detail of function
Defualt OFF
Setting ON/OFF Control
Setting Detail of function
SPL0 Not used Smart plug logic
SPL1 Using smart plug logic
Pd10 Not installation
Pd11 PDI was installed
Setting of continous cooling operation
Mode setting Effect
0 No setting
1 Cooling capacity low,Power consumption low
2 Cooling capacity mid,Power consumption mid
3 Cooling capacity high,Power consumption high
Master unit PCB DIP switch on : No.5
Select the mode using ‘▶’, ‘◀’ Button :
“Idu” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Id10” Push the ‘●’ button
EEV pulse appearing
(seg1, seg2:Idu No./seg3, seg4:Mode)
Select the Function using ‘▶’, ‘◀’ Button :
Idu No. setting and Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
Mode setting and Push the ‘●’ button
*Mode can be set 0~3 (”0” is no setting)
Setting of continous cooling operation
Comfort Cooling operation
It is function to reduce the ODU energy consumption by the continu-
ous operation without thermo off.
Mode setting method
Master unit PCB DIP switch on : No.5
Select the mode using ‘▶’, ‘◀’ Button :
“Func” Push the ‘●’ button
Select the Function using ‘▶’, ‘◀’ Button :
“Fn23” Push the ‘●’ button
Select the Option using ‘▶’, ‘◀’ Button :
“oFF”,“on” Push the ‘●’ button
Base pan Heater operation mode is set
CAUTION
• Function to prevent freezing of ODU base pan in a cold area.
• Heater is accesory.(Sold separately)
!
Base pan Heater operation
Overall Defrost Operating in Low temperature
(Heating)
Mode setting method
Power Consumption Display on wired remote
controller
Mode setting method
1,MFL67221438,영영 2018. 10. 4. 영영 11:29 Page 33
