LG MULTI V 5 ARUV408BTE5 User Manual

88
Multi V 5 Cooling Only
Outdoor Units
4. Piping Diagrams
4.1 8 / 10 / 12 RT (1 Comp)
 Cooling / Oil Return Operation
M
Electronic
Expansion Valve
Fan
Indoor Heat Exchanger
M
Electronic
Expansion Valve
Fan
Indoor Heat Exchanger
Outdoor
Temperature
Sensor
Outdoor
Unit HEX
Temperature
Sensor
Heatsink
Sub-Cooling Circuit
Inlet Temperature
Sensor
Receiver
Inlet
SC
Suction
Oil Return
Sub-Cooling Circuit
Outlet Temperature
Sensor
Charging Port
Receiver Outlet
Oil Separator
Suction
Temperature
Sensor
Low Pressure Sensor
High Pressure
Sensor
Pressure
Switch
Comp.1 Discharge
Temperature Sensor
4-Way
Valve
SC EEV
Liquid Pipe
Temperature Sensor
VI EEV
Outdoor Unit
M
Fan
Q
Motor
M
nGwG
nGwG
Gas Pipe
sGwG
sGwG
Liquid Pipe
Accumulator
Receiver
Inverter
Comp.1
High Temperature High Pressure Gas
High Temperature High Pressure Liquid
Low Temperature Low Pressure Gas
Remarks
Pressure Sensor
Pressure Switch
Temperature Sensor
SVC Valve
Check Valve
EEV
Solenoid Valve
Strainer

* 12RT have 2fans.
pG|pG|

LG MULTI V 5 ARUV408BTE5 Specifications

General

Model	ARUV408BTE5
Type	Heat Pump
Cooling Capacity	40.0 kW
Heating Capacity	45.0 kW
Refrigerant	R410A
Power Supply	380-415V, 3Ph, 50Hz
Sound Pressure Level Cooling	58 dB(A)
Refrigerant Charge	12.0 kg
Operating Temperature (Cooling)	-5 to 48°C
Operating Temperature (Heating)	-20 ~ 18 °C
