Specification
- 4 -
Copyright © 2013 - 2019 LG Electronics Inc.
All rights reserved. Only training and service purposes.
[50Hz/60Hz]
System Capacity HP
Model Name
Combination Unit
Independent Unit
Capacity
Cooling
kW
kcal/h
Btu/h
Heating
kW
kcal/h
Btu/h
Input
Cooling kW
Heating kW
Casing Color
Compressor
Type
Combination
Piston Displacement cm
3
/rev
Number of revolution rev/min
Motor Output kW
Starting Method
Oil Type
Oil Charge Amount cc
Heat Exchanger
Type
Maximum Pressure Resistance
kgf/cm
2
Head Loss kPa
Rated Water Flow LPM
Temp. range of
Circulation water
Cooling
Heating
Refrigerant
Connecting Pipes
Liquid mm(inch)
Gas mm(inch)
Water
Connecting
Pipes
Inlet mm
Outlet mm
Drain Outlet mm
Dimensions(WxHxD)
mm
inch
Net Weight
kg
lbs
Sound Pressure
Level
3)
Cooling dB(A)
Heating dB(A)
Sound Power
Level
4)
Cooling dB(A)
Heating dB(A)
Transmission Cable(CVV-SB) mm
2
Refrigerant
Name
Control Device
Power Supply V, Ø, Hz
Notes:
1. Capacities and Inputs are based on the following conditions
Cooling : Indoor temp. 27°C [80.6°F]DB/19°C[66.2°F]WB
Water inlet temp. 30°C[86°F]
Heating : Indoor temp. 20°C[68°F]DB
Water Inlet temp. 20°C[68°F]
* Interconnecting Piping Length 7.5m (25 ft.)
* Level Difference of Zero
2. Capacities are net capacities.
3. Sound pressure level is measured on the rated condition in the anechoic
rooms by ISO 3745 standard.
4. Sound power level is measured on the rated condition in the reverberation
rooms by ISO 3741 standard.
5.
Wiring cable size must comply with the applicable local and national code.
6. Due to our policy of innovation some specifications may be changed with-
out prior notification.
7.
Add an anti freeze to circulation water when outside units is operating
under 10℃(50°F), and change the DIP switch on main PCB. (For more
information, refer a installation manual.)
14 16 18
ARWN140LAS4 ARWN160LAS4 ARWN180LAS4
ARWN140LAS4 ARWN160LAS4 ARWN180LAS4
39.2 44.8 50.4
33,700 38,500 43,300
133,800 152,900 172,000
44.1 50.4 56.7
37,900 43,300 48,800
150,500 172,000 193,500
7.84 8.15 9.69
8.17 8.54 10.13
Warm Gray , Mornig Gray Warm Gray , Mornig Gray Warm Gray , Mornig Gray
Hermetically Sealed Scroll Hermetically Sealed Scroll Hermetically Sealed Scroll
(Inverter) x 1 (Inverter) x 1 (Inverter) x 1
43.8 62.1 62.1
Inverter 3,600 at 60Hz Inverter 3,600 at 60Hz Inverter 3,600 at 60Hz
4.2 5.3 5.3
Direct On Line Direct On Line Direct On Line
FVC68D(PVE) FVC68D(PVE) FVC68D(PVE)
1,200 1,400 1,400
Stainless Steel Plate Stainless Steel Plate Stainless Steel Plate
45 45 45
29 19 24
135 154 173
10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F) 10°C ~ 45°C(50°F ~ 113°F)
-5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F) -5°C ~ 45°C(23°F ~ 113°F)
12.7(1/2) 12.7(1/2) 12.7(1/2)
25.4(1) 28.58(1-1/8) 28.58(1-1/8)
PT 40 PT 40 PT 40
PT 40 PT 40 PT 40
20 20 20
(755 × 997 × 500) × 1 (755 × 997 × 500) × 1 (755 × 997 × 500) × 1
(29-23/32 x 39-1/4 x 19-11/16) x 1 (29-23/32 x 39-1/4 x 19-11/16) x 1 (29-23/32 x 39-1/4 x 19-11/16) x 1
127 x 1 140 x 1 140 x 1
280 x 1 309 x 1 309 x 1
58 53 55
57 57 56
70 65 67
69 69 68
1.0 ~1.5 x 2C 1.0 ~1.5 x 2C 1.0 ~1.5 x 2C
R410A
R410A R410A
Electronic expansion valve Electronic expansion valve Electronic expansion valve
380-415, 3, 50 380-415, 3, 50 380-415, 3, 50
380, 3, 60 380, 3, 60 380, 3, 60
