LG NANO77 Series User Manual

Kg
90°
A
D
E
F
C
G
B
5s
1s
A B C
D
(mm)
E
Wallmount
50NANO75*
50NANO77*
200 x 200 M6
Wallmount
55NANO73*
55NANO75*
55NANO77*
300 x 300 M6
Wallmount
65NANO73*
65NANO75*
65NANO77*
300 x 300 M6
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
A
C
B
D
E
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
The Analog Gender adapter can be purchased separately at Customer Service.
A
B C D E F F G
50NANO776QA 50NANO75SQA
1121 708 232 651 57.7 12.4 12.2
50NANO756QA
55NANO776QA 55NANO75SQA
1235 774 232 715 58.1 14.8 14.6
55NANO73SQA 55NANO756QA
65NANO776QA 65NANO75SQA
1454 900 271 838 58.4 22.9 22.6
65NANO73SQA 65NANO756QA
Power requirement
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.
An external audio device that
supports SIMPLINK and ARC
must be connected using
HDMI IN eARC/ARC port
When connected with a
high-speed HDMI cable, the
external audio device that
supports ARC outputs SPDIF
audio without additional audio
cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Do not look into the optical
output ports, looking at the
laser beam may damage
your vision
Audio with ACP (Audio Copy
Protection)function may
block digital audio output.
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.

LG NANO77 Series Specifications

General

Display Type	NanoCell
Refresh Rate	60Hz
Processor	α5 Gen5 AI Processor 4K
Smart TV Platform	webOS
HDMI Ports	3
USB Ports	2
AI Upscaling	Yes
Wi-Fi	Yes (Wi-Fi 5)
Ethernet	Yes
Audio Output	20W
Resolution	4K UHD (3840 x 2160)
HDR	HDR10, HLG
Voice Assistants	Google Assistant, Alexa
Bluetooth	Bluetooth 5.0
