7. Model : OJ98
Main PCB : EAX67206701
ECO NO : EKNJ400042
Change Details : R5B3, R5A8 : 0RJ4701C678(4.7KΩ, 1005, 5%, 1/16W) → 0RJ4700C678(470Ω, 1005, 5%, 1/16W)
* It should support only the model that produced before 2019.4.8
Page 9
EAX67206701 Main PCB (The Bottom surface)
Check the chip resister value
with Multi tester
After checking R5B3 or R5A8 resister value
-If it is about 4.7KΩ, Change Main board
-If it is about 470Ω,
We don’t need to change Main board
Service Bulletin
Product : Mini / Onebody / Louder
Bulletin # :
PNZ201900013-01
Release Date : 2019.08.22
