LG OK75 - Printed Circuit Board Diagrams: SMPS Bottom View

3-55 3-56
SMPS P.C.BOARD DIAGRAM
(BOTTOM VIEW)
NOTE) Warning
Parts that are critical with respect to risk
of fire or electrical shock.
Copyright © 2018 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
