Kg
5
s
1s
C
90°
A
B
D
A
B C D
(mm) (kg)
OLED48A1PTZ 1071 618 46.9 15.0
OLED55A1PTZ 1228 706 46.9 18.4
OLED65A1PTZ 1449 830 46.9 23.7
Power requirement AC 100-240 V ~ 50 / 60 Hz
The Analog Gender adapter can be purchased separately at Customer Service.
Do not look into the optical
output ports, looking at the
laser beam may damage
your vision
Audio with ACP (Audio Copy
Protection)function may
block digital audio output.
An external audio device that
supports SIMPLINK and ARC
must be connected using
HDMI IN eARC/ARC port
When connected with a
high-speed HDMI cable, the
external audio device that
supports ARC outputs SPDIF
audio without additional audio
cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.
