LG OLED48C2 Series User Manual

- 20 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
(10) Disassemble/Unfix the MAIN PCB.
(11) Disassemble/Unfix the POWER.
(12) Unfasten the HARNESS.
(13) Unfix and Disassemble the SCREW and the SUPPORTER,VESA.
2
2
2
2
1
1
1
1
Unfasten ⓑ→ⓐ
After DisAssemble
the screw
ⓐ
ⓑ
SUPPORTER,VESA
SCREW,MACHINE
BRH + 3MM 5.5MM SWCH18A FZMW N
PRESS EGI 1.6 SUPPORTER EGI 32
No
Description Qty
①
②
4
4
Specification
3
3
1
3
3
3
3
3
3
3
3
A
B
3
5
2
3
ⓑ
ⓐ
4
CHASSIS ASSEMBLY
POWER SUPPLY ASSEMBLY
SCREW,MACHINE
HARNESS,SINGLE
HARNESS,SINGLE
FREE LGP48CX-20OP LCD YY -
BRH + 3MM 5.5MM SWCH18A FZMW N
20022HS-14B2 TO 20022HS-14B2_1
20022HS 15B2 TO 20022HS 15B2 L
MAIN EDX1C OLED48CX6LA MAIN EB
No
Description Qty
①
②
③
④
⑤
1
1
12
1
1
Specification

LG OLED48C2 Series Specifications

General

Display Type	OLED
Screen Size	48 inches
Refresh Rate	120Hz
Processor	α9 Gen5 AI Processor 4K
Operating System	webOS
HDMI Ports	4
USB Ports	3
Bluetooth	Bluetooth 5.0
Ethernet	Yes
Audio Output	40W
Resolution	3840 x 2160
HDR	HDR10, Dolby Vision, HLG
Wi-Fi	Wi-Fi 6
VRR	Yes
