LG OLED48C2 Series User Manual

- 25 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
(8) Assemble SPEAKER L/R + SUPPORTER.
[Self/Successive Check]
1. [Visual Check] Check the SUPPORTER fix condition.
(9) Assemble/Fix the SUB PCB ASSY + MODULE
[Self/Successive Check]
1. [Visual Check] Check to fix the PCB with the screw for needed points.
[Key Control Point]
* When assemble the PCB and Fix with the screw, be careful not to damage at PCB.
3
3
1
3
3
3
3
3
3
3
3
A
B
3
5
2
3
ⓑ
ⓐ
4
CHASSIS ASSEMBLY
POWER SUPPLY ASSEMBLY
SCREW,MACHINE
HARNESS,SINGLE
HARNESS,SINGLE
FREE LGP48CX-20OP LCD YY -
BRH + 3MM 5.5MM SWCH18A FZMW N
20022HS-14B2 TO 20022HS-14B2_1
20022HS 15B2 TO 20022HS 15B2 L
MAIN EDX1C OLED48CX6LA MAIN EB
No
Description Qty
①
②
③
④
⑤
1
1
12
1
1
Specification
Insert
Insert Harness into the STOPPER
until Connect sound is occurred
1
2
Insert
BRACKET ASSEMBLY,SUB
SCREW,MACHINE
BRH + 3MM 5.5MM SWCH18A FZMW N
BRACKET OLED48CX - IR ASSY(IR
No
Description Qty
①
②
1
1
Specification
