LG OLED55B6P User Manual

- 7 -
LGE Internal Use Only
Copyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5. External input format
5.1. 2D Mode
5.1.1. Component input(Y, PB, PR)
5.1.2. HDMI Input (PC/DTV)
No
Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed
1
720*480i 15.73 59.94 13.50 SDTV, DVD 480I(525I)
2
720*480i 15.75 60.00 13.51 SDTV, DVD 480I(525I)
3
720*576i 15.62 50.00 13.50 SDTV, DVD 576I(625I) 50Hz
4
720*480p 31.47 59.94 27.00 SDTV 480P
5
720*480p 31.50 60.00 27.02 SDTV 480P
6
720*576p 31.25 50.00 27.00 SDTV 576P 50Hz
7
1280*720 44.96 59.94 74.17 HDTV 720P
8
1280*720 45.00 60.00 74.25 HDTV 720P
9
1280*720 37.50 50.00 74.25 HDTV 720P 50Hz
10
1920*1080 28.12 50.00 74.25 HDTV 1080I 50Hz,
11
1920*1080 33.72 59.94 74.17 HDTV 1080I
12
1920*1080 33.75 60.00 74.25 HDTV 1080I
13
1920*1080 56.25 50 148.5 HDTV 1080P
14
1920*1080 67.43 59.94 148.5 HDTV 1080P
15
1920*1080 67.50 60.00 148.5 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remarks
HDMI-PC
1 640*350 31.46 70.09 25.17 EGA
2 720*400 31.46 70.08 28.32 DOS
3 640*480 31.46 59.94 25.17 VESA(VGA)
4 800*600 37.87 60.31 40 VESA(SVGA)
5 1024*768 48.36 60.00 65 VESA(XGA)
6 1360*768 47.71 60.01 84.75 VESA(WXGA)
7 1152*864 54.34 60.05 80 VESA
8 1280*1024 63.98 60.02 109.00 SXGA Support to HDMI-PC
9 1920*1080 67.5 60 158.40 WUXGA(Reduced Blanking)
10 3840*2160 54 24.00 297.00 UDTV 2160P
11 3840*2160 56.25 25.00 297.00 UDTV 2160P
12 3840*2160 67.5 30.00 297.00 UDTV 2160P
13 4096*2160 53.95 23.97 296.70 UDTV 2160P
14 4096*2160 54 24 297 UDTV 2160P

LG OLED55B6P Specifications

General

Screen Type	oled
Wall Mount	300mm x 200mm
Tuner	digital
Screen Size	54.6 inches, 55 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
Built-In Speakers	yes
Surround Sound	other
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	0
USB Ports	3
RF Antenna	yes
Network	built-in wi-fi
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	netflix, youtube
Voice Assistant	other
Remote Control	universal
3D	no
Power Consumption	175 kilowatt hours
Depth with Stand	8.9 inches
Height with Stand	29.9 inches
Width with Stand	48.4 inches
Net Weight with Stand	41 pounds
Depth without Stand	1.9 inches
Height without Stand	28.1 inches
Net Weight without Stand	33.7 pounds
