- 18 -
Remove Stand Screw and Stand
FAB30016103 (M4*12mm), 4EA
Remove Screw 4EA first, next remove Stand
Remove Back Cover Screw
FAB31843216 (M3*5.5mm, Gray) 9EA
Common use 55”/65”
Remove PowerCord Bracket
FAB31843216 (M3*5.5mm, Gray) 1EA
Add only 55”
Pull up Power Cord, than remove
Bracket, next remove cord from PSU.
