(4) Remove Back Cover Screw
(5) Disassemble PowerCord Bracket
- Lift the Power Cord, if the Bracket is removed to
separate the Power Board and Cord.
(6) Disassemble Back Cover
- Disassemble Back Cover, lift from bottom to up
Back Cover.
Red FAB32418703 M3*5.5mm, Gray 7EA
Blue FAB31843211 M3*5.5mm, Black 3EA
Green FAB32838807 M6*10mm, VESA 4EA
To Next Page
