6.2. HDMI Input
6.2.1. HDMI1.4/2.0 (3D supported mode manually)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock
(MHz)
Proposed 3D input proposed mode
1 720*480 31.5 60 27.03 SDTV 480P 2D to 3D, Side by Side(Half), Top & Bottom
2 720*576 31.25 50 27 SDTV 576P
3 1280*720 45.00 60.00 74.25 HDTV 720P
37.500 50 74.25 HDTV 720P
4 1920*1080 33.75 60.00 74.25 HDTV 1080I
28.125 50.00 74.25 HDTV 1080I
5 1920*1080 27.00 24.00 74.25 HDTV 1080P
28.12 25 74.25 HDTV 1080P
33.75 30.00 74.25 HDTV 1080P
67.50 60.00 148.5 HDTV 1080P
56.250 50 148.5 HDTV 1080P
6 3840*2160
4096*2160
53.95 23.976 296.703 HDTV 2160P
2D to 3D,
Top & Bottom, Side by Side(half)
54 24.00 297.00 HDTV 2160P
56.25 25.00 297.00 HDTV 2160P
61.43 29.970 296.703 HDTV 2160P
67.5 30.00 297.00 HDTV 2160P
7 3840*2160 112.5 50 594 HDTV 2160P 2D to 3D, Top & Bottom(half), Side by
Side(half),
When HDMI1,2,3
UHD DEEP COLOUR ON
8 4096*2160 135 60 594 HDTV 2160P
6. 3D Mode(3D supported mode manually)
6.1. RF Input
No Resolution H-freq.(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remarks
1 1280*720 37.500 50 74.25 HDTV 720P 2D to 3D, Side by Side, Top & Bottom
2 1920*1080 28.125 50 74.25 HDTV 1080I 2D to 3D, Side by Side, Top & Bottom
