3. Remove screw 1ea, disassemble power cord from back cover
`
1
Screw : 1 EA
1
4. Remove screw 4 EA, disassemble back cover from module.
*
Put
hand
on
the
marked
area(
), separate the back cover to the top.
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
Screw : 4 EA
1
Latch : 12ea
2
18
20
