20
󱂆 Precautions for Protecting the
OLED TV Screen
Unlike regular LED/LCDs, OLED TVs produce images that emit light for each pixel, achieving a perfect black colour and delivering clear images without
blurring.
Due to the nature of the organic materials used to achieve high-resolution image quality, OLED displays generally experience image retention on the
screen, which can be a persistent phenomenon. This phenomenon is observed in all OLED panels, and although recommended picture modes can
minimise image retention, current technology cannot completely prevent this from occurring.
Displaying the same image for a long time or repeatedly displaying the same image can cause image retention on the screen, which is a common
phenomenon in OLED panel products due to the nature of the product. This product has a built-in screen protection feature. Avoid displaying images
that are likely to cause image retention, and follow the recommendations.
Images that are likely to cause image retention
Images with black areas on the top and bottom and/or the left and right sides of the screen.
Images whose aspect ratio is 4:3 or 21:9.
Images that are fixed for a long time, such as channel number, station logo, game console icon, set-top box menu, etc.
Other fixed screen images or repeatedly displayed images.
Running [Pixel Cleaning] to Protect the OLED TV Screen
The OLED TV is equipped with a Pixel Cleaning feature to check the status of the screen by itself and prevent image retention. This feature is
automatically activated when the TV is turned off after four hours of cumulative use (per day) or after 2,000 hours of cumulative use (per year).
While this feature is running, horizontal lines may appear at the top and bottom of the screen.
The pixel cleaning feature runs for approximately 1 hour and requires the power cord and main power to be connected to the product.
To run this function manually, press the
button on the remote control, go to [Support] [OLED Screen Saver] and press [Pixel
Cleaning].

Other manuals for LG OLED65C1PUB

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG OLED65C1PUB and is the answer not in the manual?

LG OLED65C1PUB Specifications

General IconGeneral
Screen shapeFlat
Display diagonal65 \
Display brightness- cd/m²
Display technologyOLED
Native aspect ratio16:9
Native refresh rate120 Hz
Contrast ratio (typical)-
Display diagonal (metric)165.1 cm
Motion interpolation technologyOLED Motion Pro
Tuner typeAnalog & digital
Digital signal format systemATSC
Smart modesCinema, Energy saving, Game, Sports, Standard, Vivid
App distribution platformLG Apps
Operating system installedWeb OS
Sound modesDolby Audio
RMS rated power40 W
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version5.0
Stand typeConnected stand
Product colorGray
Panel mounting interface300 x 200 mm
Game featuresAuto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Subtitle formats supportedASS, PSB, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
HDMI version2.2
PC in (D-Sub)No
HDMI ports quantity4
USB 2.0 ports quantity3
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)SimpLink
AC input voltage120 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)130 W
Cables includedAC
Package depth205.74 mm
Package width1676.4 mm
Package height949.96 mm
Package weight41186.19 g
Quantity per box1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Stand width998.22 mm
Depth (with stand)251.46 mm
Width (with stand)1447.8 mm
Height (with stand)861.06 mm
Weight (with stand)32613.29 g
Depth (without stand)45.72 mm
Height (without stand)830.58 mm
Weight (without stand)23995.04 g
