LG OLED65CXPUA User Manual

5
ENGENGLISH
5
EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command reference list
(Depending on model)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power* k a 00 to 01 15. Balance k t 00 to 64
02. Aspect
Ratio
k c (p.7)
16. Color
(Colour)
Temperature
x u 00 to 64
03. Screen
Mute
k d (p.7)
17. ISM
Method (Only
Plasma TV)
j p (p.8)
04. Volume
Mute
k e 00 to 01 18. Equalizer j v (p.9)
05. Volume
Control
k f 00 to 64
19. Energy
Saving
j q 00 to 05
06. Contrast k g 00 to 64
20. Tune
Command
m a (p.9)
07.
Brightness
k h 00 to 64
21. Channel
(Programme)
Add/Del(Skip)
m b 00 to 01
08. Color/
Colour
k i 00 to 64 22. Key m c Key Codes
09. Tint k j 00 to 64
23. Control
Backlight,
Control Panel
Light
m g 00 to 64
10.
Sharpness
k k 00 to 32
24. Input
select (Main)
x b (p.11)
11. OSD
Select
k l 00 to 01
25. 3D (Only
3D models)
x t (p.11)
12. Remote
Control Lock
Mode
k m 00 to 01
26. Extended
3D (Only 3D
models)
x v (p.12)
13. Treble k r 00 to 64
27. Auto
Configure
j u (p.12)
14. Bass k s 00 to 64
* Note: During playing or recording media, all commands except Power (ka) and Key (mc) are not
executed and treated as NG.
With RS232C cable, TV can communicate "ka command" in power-on or power-off status. but with
USB-to-Serial converter cable, the command works only if TV is on.

LG OLED65CXPUA Specifications

General

Screen Type	oled
Color	black
Wall Mount	300mm x 200mm
Features	hdr dynamic tone mapping pro, advanced contrast enhancer, face enhancing, ultra luminance pro, quad step noise reduction, billion rich colors
Tuner	digital
Screen Size	64.5 inches, 65 inches
Resolution	4k (2160p)
Refresh Rate	120hz
Closed Captioning	yes
HDR	yes
HDR Format	dolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	true, front firing
Surround Sound	dts-hd, dolby atmos, oled surround
Speakers Output	40 watts
HDMI Ports	4
HDMI 2.1 Ports	0
HDMI ARC Ports	yes
USB Ports	3
USB 2.0 Ports	3
Ethernet	yes
RF Antenna	yes
Bluetooth	true, 5.0
Network	built-in wi-fi, ethernet
Headphones Output	yes
Digital Optical Audio Outputs	1
Analog Audio Outputs	0
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	webos
Streaming Services	apple tv+, paramount+, crackle, disney+, fandango, google play movies & tv, hulu, netflix, pandora, peacock, prime video, redbox, showtime, sirius, starz, sling tv, spotify, twitch, vudu, youtube, youtube tv, iheartradio
Smart Applications	amazon alexa, apple homekit, google assistant
Other Devices Connection	mobile to tv
Voice Assistant	amazon alexa, google assistant
Remote Control	magic
3D	no
Power Consumption	240 kilowatt hours
Depth with Stand	9.9 inches
Height with Stand	33.9 inches
Width with Stand	57.1 inches
Net Weight with Stand	74.7 pounds
Depth without Stand	1.8 inches
Height without Stand	32.7 inches
Net Weight without Stand	55.6 pounds
