(2-1) Detach the Hinge Outer Cover below the Rear Cover by a finger.
(2-2) Unfasten the Screw 4EA at the Bottom area of Rear Cover.
2-2
2-1
2-2 2-2 2-2
2-1
2-2
OLED65G6 Disassembly Guide
