18-2
18-1
Joystick
IR
(18-1) Unfasten IR Bracket Screw 1EA.
(18-2) Unfasten Joystick bracket Screw 1EA.
OLED65G6 Disassembly Guide
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
