(11-1) Turn and put down the AV BOX like a picture. Before that, cover the table with a cotton sheet or something like that.
(11-2) To be assembled tightly, Fasten the Screw 17EA holding rear side by the other hand.
11-2 11-2 11-2 11-2 11-2 11-2 11-2 11-2 11-2
11-2 11-2
11-2 11-2 11-2 11-2 11-2 11-2
11-1
11-2
OLED65G6 Re-assembly Guide
