LG OLED65G6P-U - Page 60

MODULE Front
Remove the protection
film for Module.
b
b
c
c
c
c
c
c
Attach at
Marked Area
[Extra Guide] Working Guide to replace a Module.
(a) Remove the protection film for Module.
(b) Re-attach the Gap Pad 2EA at marked locations.
(c) Assemble Locking Brackets and Fasten Screw 6EA.
a
OLED65G6 Re-assembly Guide
