Off when on, off while viewing, power auto on/off
Established
date
Revised date
8/17
Error
symptom
Standard Repair Process
8
* Please refer to the all cases which can be displayed on power off mode.
B. Power error
Power Off History Explanation Action contents
POWER_OFF_BY_CPU_ABNORMAL
Power off by CPU Abnormal status
1. Power off (Last Cold, Last Cool, Last Warm)
Condition : When power on and checking Power on Mode, abnormality appears.
2. Power off in CPU Abnormal Case (Exception)
- Release Mode : Reboot
- Debug/Event Mode : Power off
Check & Change Main B/D
POWER_OFF_BY_CPUCMD Power off by main SoC command.
Check & Change Main B/D
POWER_OFF_BY_ABN
Case1 : Pipe line overflow
Case2 : reboot to suspend Fail
Check & Change Main B/D
POWER_OFF_BY_KEYTIMEOUT
Power off when TV is not turned off during a certain time
Result : micom force to trigger TV power off.
Condition : When pressing power key while power on/off status, CPU does not
response within 8 seconds or call the WDT timer API.
Check & Change Main B/D
POWER_OFF_BY_ACDET
Power off by not detecting AC (abnormal case)
Result : micom triggers TV power off
Condition : Power detect port drops to low while power on status.
Normal Case
Check & Change Main B/D
POWER_OFF_BY_5VMNT
Power off by not unstable AC power detect.
Result : micom check the stable power.
Condition : When AC on or DC on, stabilization check routine (Power Detect High
Check) fail after multi power on.
Check & Change Main B/D
POWER_OFF_BY_NO_POLLING
Power off when receiving no ack
Debug Status : Release Mode
Result : TV power off/on (Reboot)
Condition : There is no I2C response from CPU for 15 seconds.
if warm standby, power off occurs.
Check & Change Main B/D
POWER_OFF_BY_REMOTE_KEY2
similar with POWER_OFF_BY_KEYTIMEOUT, but different concept.
Result : micom force to trigger TV power off within 4 seconds.
Condition : When TV power on/off, CPU does not response within 4 seconds,
and then pressing power key.
Check & Change Main B/D
POWER_OFF_BY_INV_ERROR Power off by OLED module error
Check & Change OLED
Module
POWER_OFF_BY_ONRF_FAIL
Result : Reboot
Condition : OLED module compensation is running but fails.
Check & Change OLED
Module
POWER_OFF_BY_PNWASHFAIL Power off by panel noise wash function fail case. (OLED)
Check & Change OLED
Module
POWER_OFF_BY_RESUME_FAIL
Power off by resume fail when dc on case.
If occur the resume fail, TV will be rebooted.
Check & Change Main B/D
Copyright © 2019 LG Electronics. Inc. All rights reserved.
Only for training and service purposes
