You must follow the steps of this Manual. (1-1, 1-2, 2-1, 2-2, ... )
(1-1) Lay the TV SET on the flat surface table after covering a cotton sheet.
(1-2) Detach a [Cover Ass’y, Hinge Outer].
(1-3) Detach a [Cover Ass’y, Rear Outer].
(1-4) Unfasten screw 8EA at back side of [Cover Ass’y, Rear Center],
and unfasten screw 8EA at bottom side of [Base, Metal].
(1-5) Move the [Moving Handle] 2EA from STAND TYPE to WALL TYPE.
OLED77G6 Disassembly Guide
1-1
1-3
1-4
1-5
1-2
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
