(2-1) Unfasten the [Moving handle] 2EA in the middle side of [Cover Ass’y, Rear Center].
(2-2) Unfasten Screw 5EA at the bottom side of [Cover Ass’y, Rear Center].
2-1
2-1
2-1
2-2
2-2
2-2
2-2
2-2
2-2
