13-2
13-1
13-3
OLED77G6 Disassembly Guide
(13-1) Disconnect the connector 3EA of Power Cables.
(13-2) Disconnect the connector 2EA of VX1 Cables.
(13-3) Separate the [Cover Ass’y, Hinge Cable] and then put down it on the table.
(
If you change these cables, refer to the extra guide at final pages.)
