LG OLED77G6P - Page 50

PSU Mater
PSU Slave
2-1
2-1
2-1
2-1
2-2
2-2
2-2
2-3
2-4
Thermal PCB
FAN
2-1
2-1
2-1 2-2
2-2
2-2
2-2
M4 Screw 1EA
OLED77G6 Re-assembly Guide
(2-1) Fasten the [PSU Master] Screw 7EA. (It has one ground M4 screw.)
(2-2) Fasten the [PSU Slave] Screw 7EA and Connect PSU Slave Connector.
(2-3) Fasten the [Thermal PCB] Screw 1EA.
(2-4) Fasten the [Fan] Screw 2EA. (Screw Type Caution)
