LG OLED83G3 Series Service Manual

- 9 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
No. Item Specication Remarks
4 Receiving system
Digital : ATSC, 64 & 256 QAM
Analog : NTSC-M
for North America / Mexico model
Digital : SBTVD (ISDBT)
Analog : NTSC / PAL-M / PAL-N
for Central and South America model
Digital : DVB-T
Analog : NTSC / PAL-M / PAL-N
for Panama and Taiwan
► DVB-T
- Guard Interval(Bitrate_Mbit/s)
1/4, 1/8, 1/16, 1/32
- Modulation : Code Rate
QPSK/16-QAM/64-QAM
- Code Rate
1/2, 2/3, 3/4, 5/6, 7/8
Digital : DVB-T2
Analog : NTSC / PAL-M / PAL-N
for Colombia
► DVB-T2
- Guard Interval(Bitrate_Mbit/s)
1/4, 19/256, 1/8, 1/16, 1/32, 1/128
- Modulation
QPSK, 16-QAM, 64-QAM, 256QAM
- Code Rate
1/2, 3/5, 2/3, 3/4, 4/5, 5/6
Terrestrial : BST-OFDM
Satellite BS/CS : 16APSK, 8PSK, QPSK, BPSK
For Japan model
5 HDMI Input
HDMI 1
PC / DTV Format Support HDMI2.1
HDMI 2
HDMI 3
HDMI 4
6 Audio out
SPDIF(1EA) Optical Audio out
HeadPhone(1EA) HeadPhone out
7 USB Input (3EA) EMF, DivX HD, For SVC (download) JPEG, MP3, DivX HD
8 Ethernet Connect (1EA) Ethernet Connect
