LG RT-21FA31X - Exploded View Parts List

- 19 -
EXPLODED VIEW PARTS LIST
LOCA. NO PART NO DESCRIPTIONS
112 6341V21009B CPT ASSY,A51QDX992X
6341V21004B CPT A51QDX992X
6335V21008C CPT A51QDX992X
2426GDB30CD CPT SET A51QDJ279X 31M7NR
120 120-C77M SPEAKER,C122P02K1459 ESTEC 8 OHM 10/15
150 150-D02X COIL,DEGAUSSING CU 21” 60TURN 12 OHM
153 6150V-1014G DY,QPC-E5409A
6150V-1019C DY,DIF-2192AA(NF5)
170 170-A01N CPT EARTH,21” 64T 2LUG 1P HSG
300 3091V00383B CABINET ASSY
310 5020V00585A BUTTON,CONTROL
315 3580V00070A DOOR,CONTROL
3580V00064A DOOR,CONTROL
320 320-062E SPRING,COIL
330 5020V00584A BUTTON,POWER
400 3809V00277B BACK COVER ASSY
3809V00250D BACK COVER ASSY (MT LOCAL)
3809V00250K BACK COVER ASSY(SCART)
520 6871VMM745A PWB ASSY,MAIN
6871VMM745B PWB ASSY,MAIN W/O TXT
6871VMM745C PWB ASSY,MAIN
6871VMM765G PWB ASSY,MAIN RF-21FA32
6871VMM765H PWB ASSY,MAIN RF-21FA31W
6871VMM766L PWB ASSY,MAIN RT-21FA31X
6871VMMB18U PWB ASSY,MAIN RT-21FA31X
6871VMM767A PWB ASSY,MAIN LGEMT,COM
6871VMM767B PWB ASSY,MAIN LGEMT,COM
6871VMM767F PWB ASSY,MAIN LGEMT,SCART
6871VMM767G PWB ASSY,MAIN RT-21FA31G
913 332-057B SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW,TAP TITE D4.0 L16.0 MSWR3/FZB
P801 174-009E CORD,POWER(W/HOLD,HOUSING,L=200,4.0
6410VEH001D CORD,POWER
174-222P CORD,POWER SAA L=2200MM 219A
The components identified by mark is
critical for safety.
Replace only with part number specified.
