LG RT-29FB35RX - Exploded View Parts List

- 21 -
EXPLODED VIEW PARTS LIST
LOCA. No. PART No. DESCRIPTIONS
112 6334V29010B CPT, A68QCU770X 000MGB 48KHZ LPDSG S/TINT EXPORT(CASA-S)
6335V29015A CPT ASSEMBLY, A68QCU757X 770MIF 0.3G[V] 0.3G[H] LPDSG M,ITC11,S/F
120 6400VA0031A SPEAKER, GENERAL C080P22K1450 ESTEC 8 OHM 10/15W
121 4810V00573B BRAC KET, SPK RT-29FB30V C/SKD MC022A POLYESTER .
150 6140VC2005F COIL, DEGAUSSING 29 FLAT ASSY (W) SELLA TECH 2001R+D07L
153 6150V-5009B DY(DEFLECTION YOKE), 6150Z*1248G 29” LPDSG TINT
170 170-844K CPT EARTH, 29 98T 4LUG LEAD SET SPRING(50MM)
300 3091V00438U CABINET ASSEMBLY, RT-29FB35V.AMLLKX STEREO E_PHONE MC049A .
310 5020V00652E BUTTON, CONTROL RT-25FB35VX ABS, HF-380 6KEY 7227S00117A
320 320-070S SPRING, COIL
330 5020V00653D BUTTON, POWER RT-25FB35VX ABS, HF-380 1KEY 7227S00117A
400 3809V00298P BACK COVER ASSEMBLY, RT-29FB30RX SY-SET 2PHONE SY LOCAL
3809V00298Q BACK COVER ASSEMBLY, RT-29FB35RX 2PHONE SY-SET 8G068
510 6871VSMJ31B PWB(PCB) ASSEMBLY, SUB CPT MC-049A 29 FLAT+VM(W/O PIP) : LGESY
520 6871VMMT20T PWB(PCB) ASSEMBLY, MAIN MC049A RT-29FB35VX.LLLLSM8
6871VMMT52U PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB35RX.LTLLSC8
913 332-229H SCREW, DRAWING HEXAGON HEAD
943 1PTF0403116 SCREW TAP TITE(P), TRUSS HEAD D4.0 L16.0 MSWR3/FZB
P801 6410VEH001E POWER CORD, 174-009Q LGESY LOCAL KUOCHANG VDE/SEMKO
The components identified by mark is
critical for safety.
Replace only with part number specified.
