EXPLODED VIEW PARTS LIST
The components identified by mark is
critical for safety.
Replace only with part number specified.
LOCA. No. PART No. DESCRIPTIONS
104 343-B52A SUPPORTER, PCB(CF-14F20)
105 4810V00366A BRACKET, 29Q20 SUPPORTER CPT
4810V00726A BRACKET, RN-29FB50 MC022A HIPS 60HR CPT SUPPORTER
112 6334V29003A CPT, A68QCU759X 00M7ND LG-PHILIPS 48KHZ S/FOCUS RT-29FB55VB.LMLLSB8
6334V29010B CPT, A68QCU770X 000MGB 48KHZ LPDSG S/TINT EXPORT (SY-BROTHERS)
6335V29014C CPT ASSEMBLY, A68QCU759X 66M7ND +0.3G[V] 0G[H] RT-29FB55RE (ALT)
6335V29015A CPT ASSEMBLY, A68QCU757X 770MIF 0.3G[V] 0.3G[H] LPDSG M,ITC11,S/F
6335V29020R CPT ASSEMBLY, A68QCU770X54 R(-0.10G) 0G LG-PHILIPS DISPLAYS GUMI,ITC
6335V29020S CPT ASSEMBLY, A68QCU770X54 T(-0.20G) 0G GUMI,ITC RT-29FB55VQ.STLLKS
6341V29009C BARE CPT ASSEMBLY, LG A68QCU770X,1023A,TINT
120 120-C77G SPEAKER,FULLRANGE C122P02K1459 MOTOR JOY 8 OHM 10/15W 130 57*117
121 4810V00088A BRACKET, SPEAKER PP RT-29FB55RB
4810V00088B BRACKET, SPEAKER CE-29K30 PP RT-29FB55RE(ALT)
150 6140VC2005F COIL,DEGAUSSING 29 FLAT ASSY (W) SELLA TECH 2001R+D07L
6140VC2006D COIL,DEGAUSSING AL 55TURN 16OHM 0.65PIE 3270MM 26” 2007F+D07L
153 6150V-5006F DY(DEFLECTION YOKE), 6150Z-1247A 29” LPDBJ (SIGLE FOCUS)
6150V-5009A DY(DEFLECTION YOKE), 6150Z-1248G 29 LPD TINT
170 170-844K CPT EARTH, 29 98T 4LUG LEAD SET SPRING(50MM)
174 174-009E POWER CORD, POWER(W/HOLD,HOUSING,L=200,4.0
174-009V POWER CORD POWER(W/HOLD,HOUSING)L=400,4.0
6410VEH001E POWER CORD, 174-009Q VDE/SEMKO 2410MM 300 BLACK RT-29FB55RE
300 3091V00445K CABINET ASSEMBLY, RT-29FB55RB(SET) STEREO E_PHONE MC049A #117A
3091V00445L CABINET ASSEMBLY, RT-29FB55R STEREO MC049A #117 W/O EYE
3091V00445M CABINET ASSEMBLY, RT-29FB55RQ STEREO E_PHONE MC049A 117A(C/SKD)
3091V00472E CABINET ASSEMBLY, RT-29FB55RE STEREO MC049A
3091V00472F CABINET ASSEMBLY, RT-29FB55RP STEREO E_PHONE MC049A SY->ABANS
310 5020V00676C BUTTON, CONTROL RT-29FB55RB(#117A) ABS, HF-380 6KEY
5020V00715B BUTTON, CONTROL RT-29FB55RE ABS, HF-380 6KEY #117A
320 320-062E SPRING, KNOB RT-29FB55RE(ALT)
320-075B SPRING, COIL DIA:7.5MM, H:15.5MM
330 5020V00677E BUTTON, POWER RT-29FB55RB(#84B) ABS, HF-380 1KEY
5020V00716B BUTTON, POWER RT-29FB55RE ABS, HF-380 1KEY #84B
400 3809V00321A BACK COVER ASSEMBLY, RT-29FB50VE 2PHONE LGESY TOOL LOCAL
3809V00321E BACK COVER ASSEMBLY, RT-29FB50RE.LMLLSNU 1P/1D SY-SKD
3809V00321H BACK COVER ASSEMBLY, RT-29FB55VE 2PHONE HB. SY-BROTHERS
3809V00A55C BACK COVER ASSEMBLY, RT-29FB50R 2PHONE C/SKD
3809V00A55E BACK COVER ASSEMBLY, RN-29FB50T ATLLKX 51SF MC022A
3809V00A55F BACK COVER ASSEMBLY, RT-29FB50RQ 2PHONE MC-022A
510 6871VSME79A PWB(PCB) ASSEMBLY,SUB CPT MC-049A 29” FLAT+VM(W/PIP)
6871VSME79C PWB(PCB) ASSEMBLY,SUB CPT MC-049A 29” FLAT + VM(W/O PIP)
6871VSMJ31A PWB(PCB) ASSEMBLY,SUB CPT MC-049A 29” FLAT+VM(W/PIP)
6871VSMJ31B PWB(PCB) ASSEMBLY,SUB CPT MC-049A 29” FLAT+VM(W/O PIP) [LGESY]
6871VSMJ47A PWB(PCB) ASSEMBLY,SUBCPT MC-049A 29” FLAT+VM(W/O PIP) LGEIN
520 6871VMMR50K PWB(PCB) ASSEMBLY,MAIN, MC049A RT-29FB55RB.AFLLKU
6871VMMT20H PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55RE.LTLLSNT
6871VMMT20X PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55RP.LTLLSA8
6871VMMT31K PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55RQ.ALLLKR
6871VMMT39A PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55R.KTLLNI8
6871VMMT39B PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55V.KTLLNI8
6871VMMT50P PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55VQ.STLLKS3
6871VMMT50R PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55VE.AFLLKC
6871VMMT52J PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55VB.LMLLSB8
6871VMMT52X PWB(PCB) ASSEMBLY,MAIN MC049A RT-29FB55VE.LMLLSB8
570 6871VSME77A PWB(PCB) ASSEMBLY,SUB PIP MC049A W/DVD
6871VSMJ29A PWB(PCB) ASSEMBLY,SUB PIP MC-049A W/DVD : LGESY
700 0IGL120104A IC,LG SEMICONDUCTOR CDS SENSOR MODULE(P1201-04)
913 332-229H SCREW,DRAWING HEXAGON HEAD
943 1PTF0403116 SCREW TAP TITE(P),TRUSS HEAD D4.0 L16.0 MSWR3/FZB
