EXPLODED VIEW PARTS LIST
LOCA. No. PART No. DESCRIPTIONS
104 4980V00265A SUPPORTER, PCB PS 40AF FBT CA-14T30
105 343-B52A SUPPORTER, PCB(CF-14F20)
112 6341V29009C BARE CPT ASSEMBLY, LG A68QCU770X,1023A,TINT
120 120-C77G
SPEAKER,FULLRANGE C122P02K1459 MOTOR JOY 8 OHM 10/15W 130 57*117
121 4810V00088A BRACKET, SPEAKER CE-29K30 PP
150 6140VC2005F COIL,DEGAUSSING 29 FLAT ASSY (W) SELLA TECH 2001R+D07L
153 6150V-5009A DY(DEFLECTION YOKE), 6150Z-1248G 29 LPD TINT
170 170-844K CPT EARTH, 29 98T 4LUG LEAD SET SPRING(50MM)
174 174-009V POWER CORD POWER(W/HOLD,HOUSING)L=400,4.0
200 4810V00726A BRACKET, RN-29FB50 MC022A HIPS 60HR CPT SUPPORTER
300 3091V00445K CABINET ASSEMBLY, RT-29FB55RB(SET) STEREO E_PHONE MC049A #117A
310 5020V00676C BUTTON, CONTROL RT-29FB55RB(#117A) ABS, HF-380 6KEY
320 320-075B SPRING, COIL DIA:7.5MM, H:15.5MM
330 5020V00677E BUTTON, POWER RT-29FB55RB(#84B) ABS, HF-380 1KEY
400 3809V00A55E BACK COVER ASSEMBLY, RN-29FB50T ATLLKX 51SF MC022A
510 6871VSME79A PWB(PCB) ASSEMBLY,SUB CPT MC049A 29Ó FLAT + VM(W/PIP)
520 6871VMMR50K PWB(PCB) ASSEMBLY,MAIN, MC049A RT-29FB55RB.AFLLKU
550 6871VSME77A PWB(PCB) ASSEMBLY,SUB PIP MC049A W/DVD
700 0IGL120104C IC,LG SEMICONDUCTOR CDS SENSOR MODULE(P1201-04C)
913 332-229H SCREW,DRAWING HEXAGON HEAD
943 1PTF0403116 SCREW TAP TITE(P),TRUSS HEAD D4.0 L16.0 MSWR3/FZB
The components identified by mark is
critical for safety.
Replace only with part number specified.
